BCHDecoderVHDL
🧮 BCH decoder FPGA design
BCHDecoderVHDL is an open-source project aimed at designing a BCH error-correcting decoder in VHDL, built for FPGA implementation using an Avalon interface. This hardware module is integrated into a SoC system based on an Intel Cyclone V and deployed on a DE0-CV development board running at 25 MHz.
🎯 Purpose
- 🧮 Error Correction: Implements BCH decoding for binary data error detection and correction.
- 🔗 Avalon Interface Compatibility: Designed to connect seamlessly to Avalon-compliant systems.
- 🧩 Quartus Integration: Ready for integration into Intel Quartus projects targeting DE0-CV boards.
- 🧠 CPU Exploitation: Enables communication with a Nios II or other Avalon master for data exchange.
📝 Features
| 🏷️ Feature | 🔍 Description |
|---|---|
| 🧮 BCH Decoder | Implements syndrome calculation, Berlekamp-Massey algorithm, Chien Search |
| 🔗 Avalon Interface | Supports Avalon-MM or Avalon-ST as needed |
| ⚙️ VHDL Design | Modular, synthesizable VHDL code |
| 🧠 CPU-Controlled | Controlled by an Avalon master processor |
| 🧪 VHDL Testbench | Comes with a simulation testbench for functional validation |
| 🧱 DE0-CV Ready | Optimized for 25 MHz operation on DE0-CV |
| 🖥️ Quartus Project | Integrated via Qsys / Platform Designer |
| 📦 Open-source | Fully modifiable and extensible HDL source code |
📐 Design Architecture Preview
| ⚙️ Internal Architecture | 🖥️ Qsys Integration |
|---|---|
 |
 |
🗂️ Project Structure
BCHDecoderVHDL/
├── ip/
│ └── BCH/
│ ├── bch.vhd # VHDL source files
│ └── simulation/ # VHDL testbenches
├── DE0_CV.qpf # Quartus project file
├── software/ # Scripts or files related to software development
📦 Use Cases
- ✅ Embedded communication systems
- ✅ FPGA-based secure data transmission
- ✅ Educational demonstration of error-correcting codes
